Boiling Tank Boiling Disinfection Machine
1. Features:
1). Digital controlled dispaly, 0-100 ℃ heating temperature adjustable, cleaning time can be adjusted in minutes or hours to meet the cleaning requirements of different products.
2). High power heating plate or heating tube, the water can be heated to 100℃ on short time.
3). The tank body is welded by SUS304 in thickness 2.5mm, the vibration surface is plated with environmental protection chromium treatment, when the machine has no liquid level protection, the ultrasonic work will have abnormal alarm function.
4). The Exterior Panel Material is SUS304 in thickness 1.0MM, it is strong and durable.
5). Pass 2500V high voltage test, strict production process and aging process test, have mute cover/ 304 stainless steel washing basket, certificated by CE/ROSH/FCC.
6). Support full voltage from 100, 110~130, 220~240V, plug type will be matched according to your shipping address.
2. Blue Whale Medical Boiling Tank Serie Parameters
| Exterior Panel Material T1.0MM | Inner Tank Size(MM) | Tank Capacity | Material | Time Control | Heating Power | Temperature(°C) | Control Mode |
| LanJ-ZF5-1 | 500*300*300 | 45L | SUS304 | 1-99H | 3KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF6-1 | 600*300*300 | 54L | SUS304 | 1-99H | 3KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF6-2 | 600*400*300 | 72L | SUS304 | 1-99H | 3KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF6-3 | 600*400*400 | 96L | SUS304 | 1-99H | 4.5KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF7-1 | 700*300*300 | 63L | SUS304 | 1-99H | 3KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF7-2 | 700*400*400 | 112L | SUS304 | 1-99H | 6KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF7-3 | 700*500*500 | 175L | SUS304 | 1-99H | 6KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF8-1 | 800*300*300 | 72L | SUS304 | 1-99H | 3KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF8-2 | 800*400*400 | 128L | SUS304 | 1-99H | 6KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF8-3 | 800*500*500 | 200L | SUS304 | 1-99H | 9KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF9-1 | 900*300*300 | 81L | SUS304 | 1-99H | 4.5KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF9-2 | 900*400*400 | 144L | SUS304 | 1-99H | 6KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF9-3 | 900*500*500 | 225L | SUS304 | 1-99H | 9KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF10-1 | 1000*400*400 | 160L | SUS304 | 1-99H | 6KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF10-2 | 1000*500*500 | 250L | SUS304 | 1-99H | 9KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
| LanJ-ZF10-3 | 1000*600*600 | 360L | SUS304 | 1-99H | 9KW | Room temp.to 100°C adjustable | PLC controlled/digitally controlled |
3. Application
Medical hospitcal lab instruments cleaning and disinfecting.
4. Product Operating Process
1). Open the lid and add water(put more than 2/3 of the sink)
2). Add the appropriate cleaning agent.
3). Mixing the cleaning agent evenly.
4). Put in the cleaning object (soak it before washing).
5). Set time and temperature according to product needs.
6). After cleaning, disconnect the power supply, pour out the sewage, use a dry cloth to clean and maintain the tank.
5. Our Factory
Guangdong Blue Whale Ultrasonic Cleaning Technology Co., Ltd. and Guangdong Jietai Ultrasonic Cleaning Equipment Co. Ltd. are founded in 2003 and located in Dongguan City, Guangdong Province.
We have our own factory buildings including several floors of production sites and offices, we have experienced engineers, R&D team, QA team and sales team with a total around 300 workers.
We have focused on the R&D, manufacturing and sales of ultrasonic cleaning equipment. Over the past 20 years, our products have covered laboratory, medical, industrial engineering and household filed, which are widely used in the lab of schools and companies, surface coating treatment, mechanical engineering, acoustic, electronics, photoelectric, ignition detonated, medical treatment, semiconductor, watch, jewelry, PCB board, glasses, etc., and favored by customers.
With the strict impletation of ISO90001:2008 Quality Management System, our products have passed CE, FCC, ROHS and some other national and international certificates. We have got more than 50 patents. Innovation and customer-oriented are our most important corporate culture.
We welcome customers to ODM, OEM, wholesale and customize. Welcome to visit our factory.
